ATEX Speed Dome PTZ IP


Material: Designed with 304 stainless steel with superior corrosion resistance.

Lens: 5-90mm/F1.8 to 3.2, 20X Optical Zoom

Rotation Range: Horizontal 360°unlimted rotation, Vertical 90°,auto reversal

Temperature: Works effectively in temperatures between -30°C to +80°C

Waterproof protection: IP68 enclosures are Able to protect against powerful water jets which work effectively for marine areas.

Night Vision: Provides clear surveillance during nighttime.

Atex Mark: II 2G Ex db IIC T6 Gb, II 2D Ex tb IIIC(85 degree) Db

IEC Mark: Ex dIIC T6 Gb/DIP A20 TA, T6


1080P resolution, 1920(H)×1080(V)

20X optical focus, 5-90mm/F1.8 to 3.2

256 presets


Support Onvif

304 stainless steel surface treated with fluorine-carbon spray. elegant structure. explosion proof, dust proof, water proof, corrosion prevention…

Applicable for the factories having the explosive mixtures formed from class ⅡA ⅡB ⅡC T1-T6 group flammable gas, steam with air in area No.1,No.2,and appearing the explosive hazardous area due to the mixture of flammable dust and air in area  No.20,No.21 and No.22,such as oil field, chemical plant, port, oil storage, steamship, oil drilling platform, gas stations, coal mine, aviation, military, medicine, steel, firecrackers production, bank, machinery, food processing and storage and so on.

Product Name304 Stainless Steel Explosion-Proof Night Vision PTZ IP Camera
Model No.WDM-EX200IPT
Sensor2.0M Pixel 1/2.8" High-performance DSP CMOS Sensor
Output resolution1920(H)×1080(V)
D/N ModeColor, Color video anytime in low light conditions
IlluminationColor: 0.01Lux@F1.2; B/W: 0.001 Lux@F1.2
Video processingH.265 video compression, dual streaming

AVI format, 0.1M~6Mpbs adjustable;
Video Output

Main streaming:1920*1080, 1280*960, 1280×720,1024×768,1280×720;

 Sub streaming: 960×540,640×360,480×270,352×288,320×240,352×192, 320×192,288×192,256×192

Frame rate2.0MP 25/30 frame(full real time),support 1~30frame/seconds adjustable

RJ45 ethernet,10/100M;RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP protocol supported
Network interface

Standard ONVIF Protocol, Support third party access; PC;
Access ProtocolSupport IE6.0 and aboveSmartphone

Support Android\iPhone
Focus length5-90mm/F1.8 to 3.2
Optical focus20X Zoom

Support WEB configuration, OSD,real-time video transmission

Support motion detection
FunctionSupport front end storage ,playback and download

Support uniform client and platform system application

Support complete SDK for second development.
Pan Tilt
Rotation rangeHorizontal 360°unlimted rotation, Vertical 90°,auto reversal
Rotation speed        Horizontal & Vertical Min 0.01°,Max 200°/S
Housing Material
explosion-proof housing304 stainless steel, polishing passivation treatment, Rust corrosion resistance, never fade
Ingress ProtectionIP68
Interface specG-1/2”
Method of installation bracket mount
Atex MarkII 2G Ex db IIC T6 Gb, II 2D Ex tb IIIC(85 degree) Db
IEC MarkEx dIIC T6 Gb/DIP A20 TA, T6
Power supplyDC12V/POE(optional)
Working Current<=2A
